Ürün ayrıntıları

Ev Ürünler

UL94 ID10mm Non-shrink PTFE Tube 5M with High Electrical Resistance and Corrosion Resistance

Marka Adı:	None
Model numarası:	10 mm
Moq:	1
fiyat:	negotiable
Ödeme şartları:	T/T
Tedarik Yeteneği:	10000 metre gün

Ayrıntılı Bilgiler

Ürün Açıklaması

Ayrıntılı Bilgiler

Menşe yeri:

Jangsu Çin

Sertifika:

ISO9001

Malzeme:

Teflon

Boyut:

ID10mm L5M

Renk:

Beyaz, kırmızı, sarı, mavi, yeşil, siyah, şeffaf vb.

elektrik direnci:

Yüksek

Hacim Direnci:

1x10^18Ω·cm'nin üzerinde

uzama mukavemeti:

% 200'den fazla

Dielektrik Direnci:

neredeyse 2.1

Çekme Dayanımı:

13,7N/mm'nin üzerinde

Esneklik:

İyi

Su geçirmez:

su, yağ, solvent, asit, alkali direnci

Yaşlanma:

Yaşlanma karşıtı

Ambalaj bilgileri:

karton

Yetenek temini:

10000 metre gün

Vurgulamak:

Non-shrink PTFE tube 5M

PTFE tube high electrical resistance

Corrosion resistant PTFE tubing

Ürün Açıklaması

Description :

High PTFE tube with non-shrinking is extruded from high quality PTFE resin with no heat shrinkable property ,stable dimension and high mechanical strength .It features excellent high and low temperature resistance ,corrosion resistance and high insulation performance .Colored types are available for line identification ,widely used in harsh conditions such as electrical ,chemical ,medical and aerospace fields.

Key Feature :

Stable material ,non-shrinking and non-deforming ,high dimensional accuracy.
Operating temperature :-190 to 260 °C
Excellent chemical resistance to strong acids ,alkalis ,organic solvent and oils
Excellent electrical insulation ,low dielectric loss ,high insulation strengh
Low friction ,non-stick ,anti-aging ,weather resistant and UV resistant
Non-toxic and eco-friendly ,compliant with RoHS ,REACH ,partly FDA compliant
Various colors available for easy line identification

Typical applications :

Insulation sleeces for high frequency signal wires ,coaxial cables and sensors
Harness identification ,wire protection and terminal insulation
Protection tubes for transformers ,capacitors ,connectors and PCB circuits
Transfer tubes for highly corrosive chemicals and gases
Laboratory tubing ,analytical instruments and chromatograph catheters
Oil pumps ,hydraulic systems and oil and corrosion resistant sleeves
Medical catheters ,endoscope protection tubes and presion instrument sheaths
Hygienic transfer tubes for food ,beverage and filling equipment
Heat insulation tubes for engine wiring harnesses ,anti-corrosion tubes for fuel systems
Aerospace instrument wiring ,hydraulic pipelines and high temperature wire protection
